Section 104 (HVAC): Condenser: Installation

WARNING: This page is about a different car, the 2003 Subaru Forester. However, it is still accessible from the selected car via links, so may be relevant.

Install in the reverse order of removal.
CAUTION: Replace the O-rings on hoses or pipes with new ones, and then apply compressor oil. Confirm that lower guide of condenser has been fitted into holes on radiator panel.

Fig 1: Installing Condenser
Courtesy of SUBARU OF AMERICA, INC.
Charge refrigerant. Refer to OPERATION , Refrigerant Charging Procedure.
Tightening torque:
1. Refer to AIR CONDITIONING UNIT , COMPONENT, General Description and RADIATOR AND RADIATOR FAN , COMPONENT, General Description.
