Oil Pump

NOTE: The illustration for 2.5 L model is shown below. (Not shown for 3.0 L model because it cannot be disassembled.)
Fig 1: Exploded View Of Oil Pump
G02873795Courtesy of SUBARU OF AMERICA, INC.
