Throttle Body: Installation: Notes

Install in the reverse order of removal.
NOTE: Always use a new gasket.

Tightening torque:

22 N.m (2.2 kgf-m, 15.9 ft-lb)

Fig 1: Installing Engine Coolant Hoses
Courtesy of SUBARU OF AMERICA, INC.
Adjust the play of accelerator cable. < Ref. to THROTTLE CABLE . >
