Hub Unit Bearing: Disassembly

WARNING: This page is about a different car, the 2005 Subaru Baja. However, it is still accessible from the selected car via links, so may be relevant.
  1. Using ST, remove hub unit from hub assembly.
    CAUTION: Securely set hub assembly so that it does not lean.

    ST 398507703 DUMMY COLLAR

    Fig 1: Removing Hub Unit From Hub Assembly
    G03751645Courtesy of SUBARU OF AMERICA, INC.
  2. Using ST and a puller (common hand tool), remove bearing inner race.

    ST1 399520105 SEAT

    ST2 927080000 HUB STAND

    CAUTION:
    • Do not remove hub unit bearing unless damaged.
    • Replace the removed hub unit bearing with new one.
    Fig 2: Removing Bearing Inner Race
    G03751646Courtesy of SUBARU OF AMERICA, INC.
  3. Using ST, press hub bolt out.

    ST 927080000 HUB STAND

    CAUTION: Be careful not to hammer hub bolts. This may deform hub.
    Fig 3: Removing Hub Bolt
    G03751647Courtesy of SUBARU OF AMERICA, INC.
