Engine Controls (Diagnostics) (H4DOTC): Electrical Component Location: Location: Sensor

Fig 1: Identifying Sensor Components Location (1 Of 6)

Courtesy of SUBARU OF AMERICA, INC.

Fig 2: Identifying Sensor Components Location (2 Of 6)

Courtesy of SUBARU OF AMERICA, INC.

Fig 3: Identifying Sensor Components Location (3 Of 6)

Courtesy of SUBARU OF AMERICA, INC.

Fig 4: Identifying Sensor Components Location (4 Of 6)

Courtesy of SUBARU OF AMERICA, INC.

Fig 5: Identifying Sensor Components Location (5 Of 6)

Courtesy of SUBARU OF AMERICA, INC.

Fig 6: Identifying Sensor Components Location (6 Of 6)

Courtesy of SUBARU OF AMERICA, INC.
