Service Part Availability Of Revolution Sensor O-Ring (16-88-13)
Publication date: 2013-12-17Reference number: 16-88-13
SERVICE PART AVAILABILITY OF REVOLUTION SENSOR O-RING
TECHNICAL SERVICE BULLETIN
Reference Number(s): 16-88-13, Date of Issue:
December 17, 2013
| SUBARU: | All Models with CVT Transmission |
APPLICABILITY
All Models with CVT Transmission
INTRODUCTION
The sealing o-rings for the CVT revolution sensors are now available as a separate service parts. In the past, these o-rings were only available with the sensor as an assembly.
PART INFORMATION
| REVOLUTION SENSOR PART NUMBER | O-RING PART NUMBER |
|---|---|
| 31937AA071 | 806913270 |
| 31937KA060 | |
| 31937AA170 | 13099AA050 |
In addition, the applicable o-ring has been incorporated into the following gasket and seal kit part numbers: 31017AA000, 010 and 020 .
SERVICE PROCEDURE/INFORMATION
Follow the procedure in the applicable Service information for removal/installation of the revolution sensors.
NOTE:
The sealing o-ring is a one-time use part. Therefore, any time the revolution sensor is removed, the sealing o-ring must be replaced.
