ECM Connector End View

Fig 1: ECM Connector End View
G10217756Courtesy of SUBARU OF AMERICA, INC.


Fig 1: ECM Connector End View
G10214152Courtesy of SUBARU OF AMERICA, INC.


Fig 1: ECM Connector End View
G10212738Courtesy of SUBARU OF AMERICA, INC.
