Front Suspension: General Description: Specification: Rear

Sedan model

Tire size		P225/55R17 P225/50R18
Wheel arch height (Tolerance: ^{+12 mm}_{-24 mm} (^{+0.47 in}_{-0.94 in} ))	mm (in)	383 (15.08)
Camber (tolerance: ±0°45' Differences between RH and LH: 45' or less)		-1°25'
Toe-in	mm (in)	3±3 (0.12±0.12) Toe angle (sum of both wheels): 0°15'±0°15'
Thrust angle (tolerance: ±0°30')		0°

OUTBACK model

Tire size		P225/65R17 P225/60R18
Wheel arch height (Tolerance: ^{+12 mm}_{-24 mm} (^{+0.47 in}_{-0.94 in} ))	mm (in)	468 (18.43)
Camber (tolerance: ±0°45' Differences between RH and LH: 45' or less)		-1°00'
Toe-in	mm (in)	3±3 (0.12±0.12) Toe angle (sum of both wheels): 0°14'±0°14'
Thrust angle (tolerance: ±0°30')		0°

NOTE:

Front toe-in, rear toe-in and front camber can be adjusted. Adjust if the value of toe-in or camber exceeds the tolerance range of the specification chart.
Other items except for front toe-in, rear toe-in and front camber that are described in the specification chart cannot be adjusted.
If other items exceed the tolerance range of the specification chart, check the suspension parts and connections for deformation. If defective, replace with new parts.

Fig 1: Identifying Front Camber Individual Toe Angles

Courtesy of SUBARU OF AMERICA, INC.

A - B = Positive: Toe-in, Negative: Toe-out

α = Individual toe angles
