Weather Strip: Replacement: Flange

  1. Remove each weather strip - body side flange while pulling the rubber. Be careful not to tear the rubber.
  2. Replace the weather strip - trunk lid while pulling the rubber. Be careful not to tear the rubber.
    NOTE: While removing the weather strip - trunk lid, be careful not to allow adhesive to contact the trim panel - trunk side.
    Fig 1: Removing Trunk Lid Weather Strips
    G10299256Courtesy of SUBARU OF AMERICA, INC.
