Child Seat Fixing Device (ISO-FIX)
›
Exploded View
Exploded View
Fig 1: Child Seat Fixing Device (ISO-FIX) Components With Torque Specification
Courtesy of SUBARU OF AMERICA, INC.
Courtesy of SUBARU OF AMERICA, INC.
