IMPREZA Model

Fuel line 1

Fig 1: Fuel Line 1 Components (With Torque Specifications) (Impreza Model)
Courtesy of SUBARU OF AMERICA, INC.

Tightening torque: N.m (kgf-m, ft-lb)

T: 18 (1.8, 13.3)
Fuel line 2

Fig 2: Fuel Line 2 Components (With Torque Specifications) (Impreza Model)
Courtesy of SUBARU OF AMERICA, INC.

Tightening torque: N.m (kgf-m, ft-lb)

T: 8 (0.8, 5.9)
