Electronic Throttle Control Relay: Removal

  1. Disconnect the ground terminal from battery sensor. Refer to REPAIR CONTENTS>NOTE>BATTERY .
  2. Remove the electronic throttle control relay from the main fuse box.
    G13619700Courtesy of SUBARU OF AMERICA, INC.
