Intermediate Shaft: Removal

1. Remove the No. 2 brake cylinder. Ref. to AUTOMATIC TRANSMISSION>NO. 2 BRAKE CYLINDER>REMOVAL .
2. Remove the snap ring.

   Courtesy of SUBARU OF AMERICA, INC.

3. Remove the No. 3 one-way clutch and the intermediate shaft as a unit.

   Courtesy of SUBARU OF AMERICA, INC.

4. Check the No. 3 one-way clutch.
   1. Check that when it is turned clockwise it is locked, whereas when it is turned counterclockwise it turns freely.

      Courtesy of SUBARU OF AMERICA, INC.

   2. If it turns freely when turned clockwise or if it is locked when turned counterclockwise, replace with a new No. 3 one-way clutch.
5. Remove the No. 3 one-way clutch and one-way clutch inner race.

Courtesy of SUBARU OF AMERICA, INC.

(A)	One-way clutch inner race
(B)	No. 3 one-way clutch
(C)	Intermediate shaft
