Headlight Diode Removal And Installation: Notes
WARNING: This page is about a different car, the 2004 Suzuki XL-7 and 2004 Suzuki Grand Vitara. However, it is still accessible from the selected car via links, so may be relevant.
- Remove heater blower unit referring to BLOWER UNIT REMOVAL AND INSTALLATION .
- Remove headlight diode (1) from main harness (2) as shown in the figure.
