Transaxle Control Module (TCM) Installation

1. Install the TCM and nuts.
   1. Tighten the TCM mounting nuts to 23 N.m (17 lb-ft).
2. Connect the wiring connectors.
3. Connect the negative battery cable.

Fig 1: Connecting Negative Battery Cable

Courtesy of SUZUKI OF AMERICA CORP.
