A/T Shift Lock System: Wiring Diagram

Fig 1: A/T Shift Lock System - Wiring Diagram (1 Of 2)

Courtesy of SUZUKI OF AMERICA CORP.

Fig 2: A/T Shift Lock System - Wiring Diagram (2 Of 2)

Courtesy of SUZUKI OF AMERICA CORP.
