Reassembling Note for Wiring Harness
›
Around Strut
›
Left Side
Left Side
Fig 1: Identifying Left Side Wiring Harness Clips (Around Strut)
Courtesy of SUZUKI OF AMERICA CORP.
Courtesy of SUZUKI OF AMERICA CORP.
