Four Wheel Alignment Check and Adjust: Notes

Last modified: 04/01/2024 09:37:57

Courtesy of TESLA, INC.

NOTE: See Personal Protection to make sure wearing proper PPE when performing the below procedure.

Revision History:

2023-12-04: Revised procedure to be in line with latest PDS validation.
2023-06-09: Added cycle suspension ride height to High and then back to Medium when vehicle is on alignment rack with the pins pulled from the turn plates.
2023-07-19: Added Service Mode instructions.

NOTE: This procedure assumes the vehicle suspension is operating as intended. If needed, SC-19-00-007 - General Vehicle Inspection can be performed.
