CRUISE CONTROL SYSTEM MODIFICATION

TECHNICAL SERVICE BULLETIN

Reference Number(s): VOL. 7, ELC, NO. 008, Date of Issue: January 6, 1984

CRUISE CONTROL SYSTEM MODIFICATION

Model(s): 1983 - 84 Toyota Truck (RN34, 44)

Volume: 7

Reference: Electrical

Bulletin No.: 008

Date: January 6, 1984

SERVICE INFORMATION

For system standardization, a switch has been added to the cruise control circuit. This switch is incorporated in the stop light switch which has been changed from a single-contact-point type to a double-contact-point type for this purpose. See Fig 1.

Fig 1: Location of Additional Switch

PRODUCTION EFFECTIVE INFORMATION

From Frame Number	Production Date
JT4RN34** D0002889	June 1983
JT4RN44** D0144013	June 1983

PARTS INFORMATION

Previous Part Number	New Part Number	Part Name	Model
82131-89179	82131-89278	Wire, cowl	RN34, 44 M/T SR5
82131-89181	82131-89279	Wire, cowl	RN34, 44 M/T SR5, w/HAC
82131-89183	82131-89280	Wire, cowl	RN44, A/T, SRS
82131-89l89	82131-89281	Wire,cowl	RN34, 44, M/T, SR5, California Spec.
82131-89191	82131-89282	Wire, cowl	RN44, A/T, SR5 California Spec.
84340-22072	84340-24010	Switch assy, stop light	---
84340-36030	84340-24010 parts.	Switch assy, stop light	---
The new parts are not interchangeable with the previous
