Torque Specifications: RAV4
TORQUE SPECIFICATIONS (RAV4)
| Application |
Ft. Lbs. (N.m) |
| Control Shaft Lever (FWD) |
11 (15) |
| Engine Left Mounting Bolt (FWD) |
11 (15) |
| Front Suspension Crossmember Bolts/Nuts (FWD) |
| "A" |
47 (64) |
| "B" |
59 (80) |
| "C" |
83 (113) |
| "D" |
85 (115) |
| "E" |
115 (157) |
| Nut |
85 (115) |
| Starter Bolt |
27 (37) |
| Steering Gear Mounting Bolts (FWD) |
101 (137) |
| Stiffener Plate Bolt |
25 (34) |
| Torque Converter Bolt |
30 (41) |
| Transaxle Mounting Bolts |
| Front & Rear Side (FWD) |
34 (46) |
| Lower Side |
32 (44) |
| Upper Side (AWD) |
| "A" |
47 (64) |
| "B" |
34 (46) |
