Radiator ASSY: Components

WARNING: This page is about a different car, the 2004 Toyota Camry Solara. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Exploded View Of Water Pump Components (1 Of 3)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 2: Exploded View Of Water Pump Components (2 Of 3)

Fig 3: Exploded View Of Water Pump Components (3 Of 3)
