Section 448 (Driver Door Control System - Diagnostics)
›
Terminals Of Ecu
Terminals Of Ecu
WARNING:
This page is about a different car, the 2002 Toyota Prius. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Driver Door ECU Terminals
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Driver Door ECU Terminal Specifications
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
