Combination Meter
Meter, Gauges and Illumination:
PROBLEM SYMPTOMS TABLE - COMBINATION METER
| Symptom | Suspected Area |
|---|---|
| Tachometer, fuel gauge and water temperature gauge do not operate. |
|
| Speedometer does not operate. |
|
| Tachometer does not operate. |
|
| Fuel gauge does not operate or operates abnormally. |
|
| Engine coolant temperature gauge does not operate or operates abnormally. |
|
| All illumination lights do not light up. |
|
| Only one illumination light does not light up. |
|
Warning Lights:
PROBLEM SYMPTOMS TABLE - COMBINATION METER
| Symptom | Suspected Area |
|---|---|
| Warning lights do not light up. (Except discharge) |
|
| Low oil pressure warning light does not light up. |
|
| Brake warning light does not light up. |
|
| Washer level warning light does not light up. |
|
| Discharge warning light does not light up. |
|
| Seat belt warning light does not light up. |
|
