Ignition System: Preparation: Fuel: Preparation
SST
SPECIAL SERVICE TOOLS DESCRIPTION (FUEL)
| 09268-41047 | Injection Measuring Tool Set | FUEL SYSTEM (1GR-FE) FUEL SYSTEM (2UZ-FE) (From November, 2004) | |
| (09268-41091) | No.7 Union | FUEL SYSTEM (1GR-FE) FUEL SYSTEM (2UZ-FE) (From November, 2004) | |
| (09268-41110) | Adaptor | FUEL SYSTEM (1GR-FE) FUEL SYSTEM (2UZ-FE) (From November, 2004) | |
| (09268-41300) | Clamp | FUEL SYSTEM (1GR-FE) FUEL SYSTEM (2UZ-FE) (From November, 2004) | |
| (90467-13001) | Clip | FUEL SYSTEM (1GR-FE) FUEL SYSTEM (2UZ-FE) (From November, 2004) | |
| (95333-06030) | Hose | FUEL SYSTEM (2UZ-FE) (From November, 2004) | |
| (95336-08070) | Hose | FUEL SYSTEM (1GR-FE) FUEL SYSTEM (2UZ-FE) (From November, 2004) | |
| (96150-02000) | C-Ring | FUEL SYSTEM (2UZ-FE) (From November, 2004) | |
| 09808-14020 | Fuel Pump Retainer Tool | FUEL TANK ASSY (1GR-FE) FUEL TANK ASSY (2UZ-FE) (From November, 2004) | |
| (09808-01410) | Holder | FUEL TANK ASSY (1GR-FE) FUEL TANK ASSY (2UZ-FE) (From November, 2004) | |
| (09808-01430) | Bolt | FUEL TANK ASSY (1GR-FE) FUEL TANK ASSY (2UZ-FE) (From November, 2004) | |
| 09842-30070 | Wire "F" EFI Inspection | FUEL SYSTEM (2UZ-FE) (From November, 2004) | |
| 09842-30080 | Wire "H" EFI Inspection | FUEL SYSTEM (1GR-FE) |
Recommended Tools
RECOMMENDED TOOLS DESCRIPTION (FUEL)
| 09040-00011 | Hexagon Wrench Set | FUEL INJECTOR ASSY (1GR-FE) | |
| (09043-20080) | Socket Hexagon Wrench 8 | FUEL INJECTOR ASSY (1GR-FE) | |
| 09082-00040 | TOYOTA Electrical Tester | FUEL SYSTEM (1GR-FE) FUEL SYSTEM (2UZ-FE) (From November, 2004) | |
| (09083-00150) | Test Lead Set | FUEL SYSTEM (1GR-FE) FUEL SYSTEM (2UZ-FE) (From November, 2004) |
Equipment
EQUIPMENTS (FUEL)
| Clip | - |
| Measuring Flask | - |
| Ohmmeter | - |
| Radiator cap tester | - |
| Service Wire Harness | - |
| Stopwatch | - |
| Torque wrench | - |
