Laser Sensor: Removal

REMOVE RADIATOR GRILL SUB-ASSEMBLY (See REMOVAL )
REMOVE FRONT BUMPER ASSEMBLY (See REMOVAL )
REMOVE FRONT BUMPER ENERGY ABSORBER (See REMOVAL )
REMOVE FRONT BUMPER REINFORCEMENT (See REMOVAL )
REMOVE LASER SENSOR
1. Disengage the clamp, then remove the laser sensor.

  Fig 1: Removing Laser Sensor
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
