Monitor Result
Detailed information on Checking Monitor Status (See DTC CHECK / CLEAR ).
The test value and test limit information are described as shown in the following table. This information is included under MONITOR RESULT in the emissions-related DTC articles:
- MID (Monitor Identification Data) is assigned to each emissions-related component.
- TID (Test Identification Data) is assigned to each test value.
- Scaling is used to calculate the test value indicated on generic OBD II scan tools.
