Front Passenger Side Power Window Switch: Installation: Installation

INSTALL POWER WINDOW REGULATOR SWITCH ASSEMBLY
1. Engage the 2 claws to install the power window regulator switch assembly.
INSTALL POWER WINDOW REGULATOR SWITCH ASSEMBLY WITH FRONT DOOR ARMREST BASE PANEL
1. Connect each connector.
2. Engage the 7 claws and 3 guides, and install the power window regulator switch assembly with front door armrest base panel.

  Fig 1: Identifying Power Window Regulator Switch Assembly With Front Door Armrest Base, Claws And Guides
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
INSTALL ASSIST GRIP COVER
HINT:

Use the same procedure for the LH side and RH side. Refer to REASSEMBLY - Step 44 .
