3.8L - Ignition/Glow Plug System - Engine Code: CGUA
›
28 Ignition/Glow Plug System
›
Specifications
›
Spark Plug Firing Order
Spark Plug Firing Order
Fig 1: Identifying Spark Plug Firing Order
Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
The firing order is 1 - 2 - 3 - 4 - 5 - 6.
