Torque Specifications
WARNING: This page is about a different car, the 2000 Volvo S70. However, it is still accessible from the selected car via links, so may be relevant.
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|---|
| Compressor Bracket-To-Compressor | 30 (40) |
| Compressor Pipe Fitting | 15 (20) |
| Compressor Pipe Flange Bolt | 18 (24) |
| Condenser Inlet & Outlet | 19 (25) |
| Expansion Valve | 22 (30) |
| Receiver-Drier Connection | 22 (30) |
| INCH Lbs. (N.m) | |
| High-Pressure Sensor Connection | 7 (10) |
