General Service Information: Images: Views

Fig 1: Identifying Views

Courtesy of VOLVO CARS OF NORTH AMERICA.

Views are sometimes chosen that show components from another angle and which do not correspond with how you see the components when working on the car to make the images clearer. For example, this is done to show concealed screws.

When working on the bevel gear it is possible that you see it from this angle when installed in the car.
