Test 3A - Repairing Security Light Flashing Constantly

NOTE: For connector terminal identification, refer to CONNECTOR IDENTIFICATION  . For appropriate wiring diagram, see appropriate chassis wiring diagram in the WIRING DIAGRAMS article.
  1. Disconnect VTA module. See Figure in TEST 2A. Using DRB-II, check voltage at arm sense terminal No. 6 (Pink/Orange wire) of VTA module connector. If voltage is less than one volt, replace VTA module. Perform TEST VER-1  . If voltage is more than one volt, disconnect remote keyless entry module. See Fig 1 .
    Fig 1: Identifying Remote Keyless Entry Module Location
    G93H75884
  2. Using DRB-II, check voltage at arm sense circuit terminal No. 6 (Pink/Orange wire). If voltage is more than one volt, repair shorted arm sense (Pink/Orange wire). Perform TEST VER-1  . If voltage is less than one volt, replace remote keyless entry module. Perform TEST VER-1  .
