Rear Suspension - Evolution: Description: Notes
A trailing arm type multi-link suspension has been used for the rear suspension. See Fig 1 . In contrast to the trailing arm multi-link system used on the Lancer, the Lancer Evolution uses a newly developed multi-link system built on a double wishbone base to achieve superior handling stability.
