MPT Model

Set the range select lever to "P" range.
Using a plastic hammer, install the reduction driven gear assembly and new washer, and tighten new lock nut.
Tightening torque:

100 N.m (10.2 kgf-m, 73.8 ft-lb)

Fig 1: Tightening New Lock Nut
Courtesy of SUBARU OF AMERICA, INC.
After tightening, stake the lock nut securely.
Combine the transmission case with the extension case, and then install the rear vehicle speed sensor. < Ref. to INSTALLATION , Extension Case. >
Install the transmission assembly into the vehicle. < Ref. to INSTALLATION , Automatic Transmission Assembly. >
